Productinformatie
Processor |
Type processor |
Ja |
Processorfamilie |
Intel® 8ste generatie Core™ i5 |
Processormodel |
i5-8259U |
Frequentie van processor |
2,3 GHz |
Aantal processorkernen |
4 |
Processor aantal threads |
8 |
Processor lithografie |
14 nm |
Maximale turbofrequentie van processor |
3,8 GHz |
L3 cache |
6 MB |
Thermal Design Power (TDP) |
28 W |
Geheugen |
Geheugen slots type |
SO-DIMM |
Aantal geheugenslots |
2 |
Maximum intern geheugen |
32 GB |
Supported memory clock speeds |
2400 MHz |
Ondersteunde geheugen types |
DDR4-SDRAM |
Geheugen kanaal |
Dual |
Geheugen bandbreedte (max) |
38,4 GB/s |
Geheugen voltage |
1.2 V |
ECC |
Nee |
Opslagmedia |
Ondersteunde types opslag-drives |
HDD, SSD |
Aantal storage drives ondersteund |
2 |
Soorten RAID |
0, 1 |
Geïntegreerde geheugenkaartlezer |
Ja |
Compatibele geheugenkaarten |
MicroSDXC |
Grafisch |
Ingebouwde grafische adapter |
Ja |
Grafische adapter-familie |
Intel |
Grafische adapter |
Iris Plus Graphics 655 |
Maximum geheugen grafische adapter |
32768 MB |
Aantal displays ondersteund |
3 |
Netwerk |
Ethernet LAN |
Ja |
Wifi |
Ja |
Wi-Fi-standaarden |
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Bluetooth |
Ja |
Bluetooth-versie |
5.0 |
Poorten & interfaces |
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A |
4 |
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C |
1 |
Aantal Internal USB 2.0 ports |
2 |
Aantal HDMI-poorten |
1 |
HDMI versie |
2.0a |
Combo koptelefoon/microfoon port |
Ja |
Aantal Ethernet LAN (RJ-45)-poorten |
1 |
Consumer Infrared Headers |
Ja |
Hoeveelheid Thunderbolt ports |
1 |
Aantal SATA III connectors |
2 |
Aansluiting voor netstroomadapter |
Ja |
Uitbreidingsmodules |
PCI Express slots versie |
3.0 |
PCI Express x4 slots |
1 |
Aantal M.2 (M) slots |
1 |
Design |
Type behuizing |
UCFF |
Kleur van het product |
Zwart |
Type koeling |
Actief |
LED-indicatoren |
Ja |
Bevestigingsmogelijkheid voor kabelslot |
Ja |
Kabelslot sleuf type |
Kensington |
Type product |
Mini PC barebone |
ARK ID |
126148 |
Veiligheid |
IEC 60950-1, UL 60950-1, EN 60950-1, CAN/CSA-C22.2 No. 60950-1 |
Certificering |
CISPR 32, FCC, ICES, EN, ETSI EN, AS/NZS, VCCI, KN, CNS, RoHS, WEEE |
Productfamilie |
Intel NUC |
Productserie |
Intel NUC kit |
Productcodenaam |
Bean Canyon |
Prestatie |
Moederbord form factor |
UCFF |
Processor socket |
BGA 1528 |
Aantal ondersteunde processoren |
1 |
Compatibele processors |
Intel Core i5 |
BIOS type |
EEPROM |
Grootte BIOS-geheugen |
64 Mbit |
Systeem Management BIOS (SMBIOS) versie |
2.5 |
Trusted Platform Module (TPM) |
Nee |
Audio-uitgangskanalen |
7.1 kanalen |
Processor speciale functies |
Intel® High Definition Audio (Intel® HD Audio) |
Ja |
Ingebouwde opties beschikbaar |
Nee |
Intel® Virtualization Technology (Intel® VT) |
VT-d, VT-x |
Intel® Rapid Storage Technology |
Ja |
Intel® vPro™ Technology |
Nee |
Intel® AES New Instructions (Intel® AES-NI) |
Ja |
Intel® Quick Sync Video Technology |
Ja |
Intel® InTru™ 3D Technology |
Ja |
Intel® Clear Video HD Technology (Intel® CVT HD) |
Ja |
Intel® Turbo Boost Technology |
2.0 |
Intel® Hyper Threading Technology (Intel® HT Technology) |
Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) |
Ja |
Intel® VT-x with Extended Page Tables (EPT) |
Ja |
Intel® 64 |
Ja |
Intel® My WiFi Technology (Intel® MWT) |
Ja |
Idle States |
Ja |
Enhanced Intel SpeedStep Technology |
Ja |
Thermal Monitoring Technologies |
Ja |
Intel® Flex Memory Access |
Ja |
Intel® Identity Protection Technology (Intel® IPT) |
Ja |
Intel® Trusted Execution Technology |
Nee |
Execute Disable Bit |
Ja |
Intel® Visual BIOS |
Ja |
Intel® Express BIOS-update |
Ja |
Intel® TSX-NI |
Nee |
Intel® Secure Key |
Ja |
Intel® Stable Image Platform Program (SIPP) |
Nee |
Intel® OS Guard |
Ja |
Intel® Clear Video-technologie |
Ja |
Intel® Optane™ Memory Ready |
Ja |
Intel® Platform Trust Technology (Intel® PTT) |
Ja |
Energie |
Soort voeding |
Externe AC-adapter |
Netvoeding |
90 W |
Eisen aan de omgeving |
Bedrijfstemperatuur (T-T) |
0 - 40 °C |
Temperatuur bij opslag |
-20 - 60 °C |
Gewicht en omvang |
Breedte |
117 mm |
Diepte |
112 mm |
Hoogte |
51 mm |
Inhoud van de verpakking |
Extra informatie |
Model wordt zonder C5 powerkabel geleverd |
Overige specificaties |
DC voltage input |
12-19 DC |
